Gigabyte GP-P650G ATX 650W 80 PLUS Bronze Power Supply Unit
Gigabyte GP-P650G ATX 650W 80 PLUS Bronze Power Supply Unit
650W power output | 80 PLUS Bronze efficiency | Compact ATX form factor | Active cooling with 120mm fan
Regular price
£68.80 GBP
(incl. VAT)
Regular price
Sale price
£68.80 GBP
(incl. VAT)
Unit price
/
per
Shipping calculated at checkout.
In stock: 6
Couldn't load pickup availability
- Trusted by Thousands
- Order with confidence
- Fully tracked shipping
Product Description:
Product Description: 650W, ATX, 12V, 80 Plus Bronze
GIGABYTE GP-P650G. Total power: 650 W, AC input voltage: 100 - 240 V, Input current: 12 - 6 A. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
Key Features:
- 80 PLUS Gold certified
- 120mm Smart Hydraulic Bearing (HYB) Fan
- Main Japanese capacitors
- Powerful single +12V rail
GIGABYTE GP-P650G. Total power: 650 W, AC input voltage: 100 - 240 V, Input current: 12 - 6 A. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
Key Features:
- 80 PLUS Gold certified
- 120mm Smart Hydraulic Bearing (HYB) Fan
- Main Japanese capacitors
- Powerful single +12V rail
Usage:
Install the power supply unit into your PC case. Connect the 20+4 pin ATX motherboard power cable and other necessary connectors. Ensure proper ventilation for the active cooling fan to operate efficiently.
Key Product Details:
MPN: GP-P650G
EAN: 4719331556785
Manufacturer: Gigabyte
Condition: New
Technical Specifications:
| Depth | 150 mm |
|---|---|
| Width | 140 mm |
| Height | 86 mm |
| Purpose | PC |
| ATX version | 2.31 |
| Noise level | 39 dB |
| Total power | 650 W |
| Cabling type | Non-Modular |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Fan location | Top |
| Package type | Box |
| Input current | 12 - 6 A |
| On/off switch | Yes |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| AC input voltage | 100 - 240 V |
| Bearing technology | HDB |
| Combined power (+5V) | 650 W |
| 80 PLUS certification | 80 PLUS Bronze |
| Combined power (+12V) | 650 W |
| Combined power (-12V) | 3.6 W |
| CPU power cable length | 60 cm |
| Combined power (+3.3V) | 120 W |
| Combined power (+5Vsb) | 12.5 W |
| SATA power cable length | 150,500 mm |
| CPU P4 connector (4-pin) | 1 |
| Max output current (+5V) | 20 A |
| Max output current (+12V) | 54.17 A |
| Max output current (-12V) | 0.3 A |
| Power protection features | Over power, Overcharge, Short circuit, Under voltage |
| Max output current (+3.3V) | 20 A |
| Max output current (+5Vsb) | 20 A |
| Floppy disk drive connector | Yes |
| Motherboard power connector | 20+4 pin ATX |
| CPU power connector (4+4 pin) | Yes |
| Maximum input current (@110V) | 12 A |
| Maximum input current (@220V) | 6 A |
| ATX power connector (20+4 pin) | Yes |
| Motherboard power cable length | 50 cm |
| PCI Express power cable length | 65 cm |
| Number of SATA power connectors | 6 |
| Mean time between failures (MTBF) | 100000 h |
| Power Factor Correction (PFC) type | Active |
| Power supply unit (PSU) form factor | ATX |
| Peripheral (Molex) power cable length | 150,500 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
